Electric Double Layer Capacitors
63 Results
Results per page :
Selected :
Search again
Search by Usage
Display item
| All | Series | Part Number | Purchase | Status | Category Lower Limited Temperature (℃) |
Category Upper Limited Temperature (℃) |
Rated Voltage Range (V.D.C) |
Rated Capacitance (F) | Capacitance Tolerance (%) | Product diameter : D(mm) |
Product height : L(mm) |
ESR(mΩ) (at 1kHz) |
DCR Typical（mΩ） |
Endurance (h) | Weight (g) | Minimum Quantity | Product category | Type | Product summary |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| JUW | JUWT1826MHD |
 |
LTB | -25 | 70 | 2.7 | 82.0 | -20～20 | 18.0 | 40.0 | 60 | 130.0 | 1,000 | 16.0 | 200 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1476MHD |
|
LTB | -25 | 70 | 2.7 | 47.0 | -20～20 | 18.0 | 31.5 | 100 | 220.0 | 1,000 | 15.0 | 250 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1336MHD |
|
LTB | -25 | 70 | 2.7 | 33.0 | -20～20 | 16.0 | 31.5 | 120 | 280.0 | 1,000 | 9.0 | 250 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1226MHD |
|
LTB | -25 | 70 | 2.7 | 22.0 | -20～20 | 12.5 | 31.5 | 200 | 400.0 | 1,000 | 5.0 | 500 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1126MPD |
|
LTB | -25 | 70 | 2.7 | 12.0 | -20～20 | 10.0 | 31.5 | 300 | 600.0 | 1,000 | 5.0 | 1000 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1685MHD |
|
LTB | -25 | 70 | 2.7 | 6.8 | -20～20 | 12.5 | 20.0 | 300 | 700.0 | 1,000 | 3.0 | 800 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1475MPD |
|
LTB | -25 | 70 | 2.7 | 4.7 | -20～20 | 10.0 | 20.0 | 400 | 800.0 | 1,000 | 2.0 | 1000 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1335MPD |
|
LTB | -25 | 70 | 2.7 | 3.3 | -20～20 | 10.0 | 12.5 | 500 | 1,100.0 | 1,000 | 1.6 | 1000 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1275MPD |
|
LTB | -25 | 70 | 2.7 | 2.7 | -20～20 | 8.0 | 20.0 | 600 | 1,200.0 | 1,000 | 1.5 | 2000 | EDLC | Radial Lead | Hi-Cap. | |
| JUW | JUWT1155MPD |
|
LTB | -25 | 70 | 2.7 | 1.5 | -20～20 | 8.0 | 11.5 | 1,200 | 2,500.0 | 1,000 | 1.0 | 2000 | EDLC | Radial Lead | Hi-Cap. |
